Upright Metallurgical Microscope

Upright Metallurgical Microscope
Upright Metallurgical Microscope
Product Code : 03
Product Description

Upright Metallurgical Microscope

Leveraging on our wide expertise and skills, we are renowned as one of the most profound manufacturers & exporters of Upright Metallurgical Microscope. We follow stringent quality control measures at each & every level of production process, so that we can deliver excellent quality microscopes to our clients. These microscopes are used to observe transparent and opaque objects. Available in different specifications, our offered Upright Metallurgical Microscope is known for its sturdy construction, accurate result and unmatched performance.

Further Details:



We provide upright metallurgical microscope with following features:

MECHANICAL BODY:
Main body consists of :

  • (a)- Co-axial focussing system with PRE-FOCUSSING LEVER & TENSION ADJUSTMENT RING.
  • (b)-Quadruple nosepiece revolves on ball bearings.
  • (c)-Mechanical stage size 125mmX130mm low positioned co-axial controls on ball bearing guideways.
  • (d)-Backelite arm rests on both sides of base.

TRINOCULAR HEAD

  • Trinocular Siedentopf head rotable at 360 degree. Binocular head inclined at 30 degree.
  • Vertical phototube for photomicrography.
  • Light path selector lever to direct either full light to observation head or 80% to vertical phototube and 20% to observation tube.

ILLUMINATOR

  • The reflected light illuminator has 6V-20W Halogen lamp with intensity control knob and built-in polariser.

EYEPIECE

  • Wide Field Eyepiece 10X (Paired) FN 18mm

OBJECTIVES

  • DIN (ZERO CORRECTED)
  • 4X, 10X, 40X, & 100X (SL) Oil
  • 6V / 20W halogen Tungsten Bulb (Spare)
  • Styrofoam Moulded Pack.
